ARRI ALEXA Mini Cinema Camera
ARRI ALEXA Mini Cinema Camera
Compact Versatility, Cinematic Excellence
The ARRI ALEXA Mini is a marvel of camera engineering, combining the unparalleled image quality of the ARRI ALEXA series with a compact, lightweight design. Tailored for versatility, the ALEXA Mini is the perfect tool for any cinematographer looking to push creative boundaries without being weighed down.
Features at a Glance:
- Super 35mm Sensor: Experience the cinematic look and feel that has become synonymous with ARRI, thanks to the ALEXA Mini’s Super 35mm sensor. With a dynamic range of 14+ stops and ARRI’s renowned color science, the Mini captures stunning, lifelike images in any situation.
- 4K UHD, HDR, and HFR Recording: The ALEXA Mini supports recording in various resolutions and formats, including 4K UHD, High Dynamic Range (HDR), and High Frame Rate (HFR) up to 200fps, allowing for breathtaking slow-motion shots.
- Compact and Lightweight Design: Engineered for agility, the ALEXA Mini is ideal for gimbal, handheld, and drone shooting. Its small footprint does not compromise on power or functionality, making it a favorite among filmmakers worldwide.
- ARRIRAW and ProRes Recording: Offering flexibility in post-production with support for both ARRIRAW and ProRes recording formats. Whether you’re shooting a feature film, commercial, or documentary, the ALEXA Mini fits seamlessly into any workflow.
- Wireless Control and Integrated ND Filters: Equipped with built-in wireless control and motorized ND filters, the ALEXA Mini is designed for efficiency on set. Adjust settings remotely and adapt to changing light conditions without missing a beat.
- Robust and Reliable: Built to ARRI’s exacting standards, the ALEXA Mini is as durable as it is advanced. Whether on a studio lot or on location in extreme environments, this camera stands up to the challenges of professional film production.
ITEMS | QTY |
Alexa Mini Body w/ Tilta Cage and 15mm LWS Baseplate | 1 |
Alexa Mini Multi Viewfinder MVF-1 w 3.2″ LCD | 1 |
29” Viewfinder Cable for the Arri Alexa Mini Camera | 2 |
CABLES | QTY |
Arri KC-50 Straight Power Cable | 2 |
Alexa Mini Remote Stop Adapter Cable | 1 |
Wooden Camera A-Box Audio Adapter | 1 |
7 pin lemo EXT Connect cable | 1 |
Arri swivel antenna (83 mm) for Alexa cameras and motor controllers | 1 |
Alexa Mini Audio Connector with cable (5 pin mini lemo to 5 pin XLR) | 1 |
Run Stop Cable | 1 |
MEDIA | QTY |
SanDisk 256Gb CFast Card | 4 |
Codex C-Fast 2.0 Card Reader (CDX-7515) | 1 |
USB to mini USB cable | 1 |
Sensor Type |
Super 35 format ARRI ALEV III CMOS sensor with Bayer pattern color filter array
|
|||
Sensor Maximum Number
|
3424 x 2202 | |||
of Photosites and Size
|
28.25 x 18.17 mm / 1.112 x 0.715″
|
|||
⌀ 33.59 mm / 1.322″ | ||||
Built-In ND Filter | 2, 4, and 7 stop ND Filters | |||
Sensor Frame Rates | 0.75 – 200 fps | |||
Weight | ∼2.3 kg / ∼5 lbs |
(camera body with titanium PL lens mount)
|
||
Recording Format | Maximum Frame Rate in fps |
|||
Sensor
Mode |
Recording
File Type |
Recording
Resolution |
Recording File
Setting |
Internal Recording |
CFast 2.0 128 GB | ||||
16:9
|
ProRes
|
HD, 516 HD
|
422 / 422 HQ | 200 |
4444 | 200 | |||
4444XQ | 120 | |||
2K
|
422 / 422 HQ | 200 | ||
4444 | 200 | |||
4444XQ | 120 | |||
3.2K
|
422 / 422 HQ | 60 | ||
4444 | 60 | |||
4444XQ | 30 | |||
UHD
|
422 / 422 HQ | 60 | ||
4444 | 60 | |||
4444XQ | 30 | |||
MFX/ARRIRAW | 16:9 2.8k | – | 48 | |
4:3
|
ProRes
|
4:3 2.8K
|
422 / 422 HQ | 50 |
4444 | 50 | |||
4444XQ | 50 | |||
6:5*
|
ProRes
|
2:39:1 2K Ana.
|
422 / 422 HQ | 120 |
4444 | 120 | |||
4444XQ | 120 | |||
8:9**
|
ProRes
|
HD Ana.
|
422 / 422 HQ | 120 |
4444 | 120 | |||
4444XQ | 120 | |||
Open Gate | MFX/ARRIRAW | 3.4K Open Gate | 30 |
